Hyundai Azera: Front Muffler Components and Components Location
Fifth generation HG (2011–2024) / Hyundai Azera 2011-2024 Service Manual / Engine Mechanical System / Intake And Exhaust System / Front Muffler Components and Components Location
Fifth generation HG (2011–2024) / Hyundai Azera 2011-2024 Service Manual / Engine Mechanical System / Intake And Exhaust System / Front Muffler Components and Components Location
| Components |
| 1. Front muffler |
Exhaust Manifold Repair procedures
Removal and Installation
[LH]
1.
Disconnect the LH front and rear heated oxygen sensor (HO2S) connector.
(Refer to Fuel System - "Heated Oxygen Sensor (HO2S)")
2.
Remove the front muffler ...
Front Muffler Repair procedures
Removal and Installation
1.
Disconnect the battery negative terminal.
2.
Remove the engine room under cover.
3.
Disconnect the heated oxygen sensor (HO2S) connector.
(Refer to Fuel Sys ...
