Description and Operation
Description
Tread Lamp
-
Tire Under Inflation / Leak Warning.
1.
Turn on condition
A.
When tire pressure is below allowed threshold
B.
When rapid leak is detected by the sensor.
2 ...
Side Impact Sensor (SIS) Repair procedures
Removal
Front Side Impact Sensor
1.
Disconnect the battery negative cable and wait for at least three minutes before beginning work.
2.
Remove the door scuff trim.
(Refer to Body - "Door sc ...
Schematic Diagrams
MDPS Circuit Diagram
Harness Connector
TypePin NoDescriptionBattery1Battery +2Battery -Vehicle1IGN2-3-4-5-6-7High_CAN8Low_CAN
...
