Manifold Absolute Pressure Sensor (MAPS) Repair procedures
Inspection
1.
Connect the GDS on the Data Link Connector (DLC).
2.
Measure the output voltage of the MAPS at idle and IG ON.
ConditionOutput Voltage (V)IG ONApprox. 4.44VIdleApprox. 0.75V
...
Repair procedures
On-vehicle Inspection
Spark Test
1.
Remove the ignition coils.
(Refer to Ignition System - "Ignition Coil")
2.
Using a spark plug socket, remove the spark plug.
3.
Install the spark p ...
Output Speed Sensor Schematic Diagrams
Circuit Diagram
...
